Product wetted materials
|
Stainless steels, Nickel based alloys such as Hastelloy C 22 or Alloy 59, Titanium, etc., |
| Sealing materials |
PTFE gaskets, O-Rings in FFKM or FEP encapsulated |
| Area classification |
EU-Type Examination Certificate INERIS the 2014/34/EU Directive, or with electrical components UL approved for operation in a Class 1, Division 1 or 2, Groups C&D environment |
Controls
|
Control cabinet with PLC, HMI with touch screen, MCC, interface for DCS |
Guidelines
|
Calculation, design and manufacture in accordance with the Pressure Equipment Directive (PED) 2014/68/EU and /or the ASME pressure vessel code, Section VIII, with U-Stamp |
Filter area
|
2.0 to 16 m² |
Slurry volume
|
2,000 – 40,000 liters |
Design temperature
|
-10 to 150°C (14 to 302°F) or per requirements |
Design pressure
|
-1 to +4 barg (FV to 60 psig) or per requirements |
Accessories
|
Heated vessel and agitator, openable filter bottom, dust filter with automatic back cleaning, sampling valve, CIP system, sight glass with vessel light, vacuum system with condenser, heating and cooling unit etc. |
