| Product wetted materials |
Stainless steels, Nickel based alloys such as Hastelloy C 22 or Alloy 59, Titanium, etc., |
| Sealing materials |
PTFE gaskets, O-Rings in FFKM or FEP encapsulated |
| Area classification |
EU-Type Examination Certificate INERIS the 2014/34/EU Directive, or with electrical components UL approved for operation in a Class 1, Division 1 or 2, Groups C&D environment |
| Controls |
Control cabinet with PLC, HMI with touch screen, MCC, interface for DCS |
| Guidelines |
Calculation, design and manufacture in accordance with the Pressure Equipment Directive (PED) 2014/68/EU and /or the ASME pressure vessel code, Section VIII, with U-Stamp |
| Usable volume |
1,000 – 40,000 liters |
| Design temperature |
-10 to 150°C (14 to 302°F) or per requirements |
| Design pressure |
-1 to +0,45 barg (FV to 6,5 psig) or per requirements |
| Heated areas |
All product wetted components, including agitator sgaft arms and blades |
| Accessories |
Dust filter with automatic back cleaning, sampling valve choppers, sight glass with vessel light, vacuum system with condenser, heating and cooling unit etc. |
