| Temperatures |
Orbital system: Operating temperature 160°C
Central shaft: Operating temperature 240°C |
| Pressure |
Operating pressure: -1 bar up to +6 bar (10 bar ESP explosion shock proof design, different pressure acc. customer requirement) |
| Materials |
Stainless steel such as:
- AISI 304
- AISI 316L
- AISI 316
- AISI 904L
- Hastelloy C22
|
| Surface finish |
Product contact – fine polish / electro-polish
Externals – sanitary polish / glass blast bead |
| Variations |
Optimized versions and specialized details for chemical and pharmaceutical application or according customized requirements |
| Rotary shaft seals |
From single- or multiple lip seal assembly to dry, gas-purged or liquid quench, non-contact lift-off mechanical seals. Preferred in a safe and quick change cartridge design. |
| Regulations/ Standards |
- European PED Pressure Equipment Directive with AD-2000 calculation
- ASME and ASME Code VIII
- GB150
- SELO
- SVDB
- CODAP
- JIS
- GOST certificate
- GMP and cGMP
- FDA
- REACH regulation
- ATEX / NEC / CEC / IEC
- TA Luft (air quality control)
|
| Options |
- Diverse sensors for temperature and pressure monitoring
- Sampling valves (also with containment)
- Filling and discharge valves
- WIP / CIP / SIP nozzles
- Filter with reverse jet cleaning
- Heating jacket / insulating jacket
|
